FR100GK Orange

  • 98CC high performance engine;
  • Use high-performance automatic clutch;
  • The seat height is adjusted to exceed 120mm stroke;
  • Use High performance rear disc brake;
  • Use C & U bearing;
  • Use KMC chain;
  • High quality alloy rear spindle;
  • Wanda/Junkai tires;


Vehicle Model name FR100GK
Engine Type: DK156F (98CC)
Cooling mode Fan cooled
Number of stroke 4-stroke
Number of cylinders 1-cylinder
Bore×Stroke: φ56×40
Compression Ratio: 8.5:1
Carburetor: /
Ignition: CDI
Starting: Pull start
Fuel Type Gasoline
Transmission: Automatic Clutch
Drive Train: Chain drive
Gear Ratio 8.3:1
Max. Power: 1.85kw/3600r/min
Max. Torque: 4.8N.m/2500r/min
Engine Oil Capacity: 0.4L
Transmission Oil Capacity: /
Suspension/Front: double shock absorber
Suspension/Rear: Single shock absorber
Brakes/Front: /
Brakes/Rear: Disc Brake
Tires/Front: 14*4.10-6
Tires/Rear: 14*5.0-6
Overall Size (L×W×H) 1460×840×1080
Seat Height: (mm) 200
Wheelbase: (mm) 924
Ground Clearance: (mm) 130
Battery: /
Charger /
Fuel Capacity: 1.6L
Dry Weight: 78kg
Gross Weight: 84KG
Max. Load: 68kg
Package Size: 1380×830×520mm
Max. Speed: ≥30km/h
Rims Steel
Muffler Steel
Loading Quantity: 110pcs/40´HQ
Certificates CE, UKCA, EPA, Carb
Option Parts: Rims Cover
Full Roll cage
