| Vehicle Model name | FR5DXMB |
| Engine Type: | Permanent magnet brushless motor |
| Cooling mode | / |
| Number of stroke | / |
| Number of cylinders | / |
| Bore×Stroke: | / |
| Compression Ratio: | / |
| Carburetor: | / |
| Ignition: | / |
| Starting: | / |
| Fuel Type | Electric Model |
| Transmission: | / |
| Drive Train: | Chain drive |
| Gear Ratio | 6.5：1 |
| Max. Power: | 1KW |
| Max. Torque: | 13N.m |
| Engine Oil Capacity: | / |
| Transmission Oil Capacity: | / |
| Suspension/Front: | |
| Suspension/Rear: |
| Brakes/Front: | |
| Brakes/Rear: | Disc Brake |
| Tires/Front: | 145/70-6 |
| Tires/Rear: | 145/70-6 |
| Overall Size (L×W×H) | 1450×680×930 |
| Seat Height: | 650 |
| Wheelbase: | 1050 |
| Ground Clearance: | 150 |
| Battery: | 48V12AH Lead Acid |
| Charger | AC100~240V, DC56V2A,ETL/UL |
| Fuel Capacity: | / |
| Dry Weight: | 52kg |
| Gross Weight: | 61kg |
| Max. Load: | 68kg |
| Package Size: | 1000×390×660mm |
| Max. Speed: | ≥30km/h |
| Rims | Steel |
| Muffler | Steel |
| Loading Quantity: | 280pcs/40´HQ |
| Certificates | CE, UKCA |
