Vehicle Model: FR200 ATV-UT |
Brakes/Front: Disc Brake |
Engine Type: 162FM (180CC) |
Brakes/Rear: Disc Brake |
Cooling mode: Air cooled |
Tires/Front: 23×7-10 |
Number of stroke: 4-stroke |
Tires/Rear: 22×10-10 |
Number of cylinders: 1-cylinder |
Overall Size (L*W*H): 1650x980x1110mm |
Bore * Stroke: @62.5×57.8 |
Seat Height:780mm |
Compression Ratio: 9.0:1 |
Wheelbase: 1080 |
Carburetor: PD226J |
Ground Clearance: 130mm |
Ignition: CDI |
Battery: 129Ah |
Starting: Electrical start |
Fuel Capacity: 4.5L |
Fuel Type: Gasoline |
Dry Weight: 176kg |
Transmission: F-N-R |
Gross Weight: 205KG |
Drive Train: Chain drive |
Max. Load: 120kg |
Gear Ratio: 37: 17 |
RaCkage Size: 1470×1050 |
Max. Power: 8.2KW/75001500 |
Max. Speed: 255km/h |
Max. Torque: 12Nm/5500÷500 |
Rims: Steel |
Engine Oil Capacity: 0.9L |
Muffler: Steel |
Suspension/Front: Independent double shock absorber Loading Quantity: 48pcs/40’HQ |
|
